48V 100Ah Wall-Mount LiFePO4 Battery front view with display

1 / 3

Lithium-ion BatteriesNoor SKU: NS-BAT-48100W

48V 100Ah Wall-Mount LiFePO4 Battery

5.12 kWh architectural wall-hanging energy storage unit with front-panel status display and integrated DC breaker.

Internal Noor SKU:NS-BAT-48100W

Stock Availability:On Request / Container Indent

Wholesale Tier:Wholesale orders from 1 pallet

Container Inquiries:Container pricing available on request

Delivery Lead Time:Contact for batch quote

Request Wholesale Quotation

Direct B2B wholesale supply • Wholesale orders from 1 palletContainer pricing available on request

Engineering Summary

Designed for commercial offices and residential installations where floor space is limited and aesthetics matter. Includes an integrated LCD display showing state-of-charge, voltage, and health status with simple wall bracket installation.

Supplied with Complete Technical Datasheet

Warranty & Support

Factory Terms

Performance Warranty:>6,000 cycles @ 80% DOD

Manufacturer Warranty Backing

Standard warranty terms are provided and backed directly by the original equipment manufacturer.

Local Supplier RMA Coordination

Noor Solar Energy serves as the local technical liaison in Bangladesh, coordinating on-site diagnostics, factory RMA claims, and authorized component replacement with the manufacturer.

RMA Claim Submission:To initiate an RMA support claim, submit the original commercial invoice, serial numbers, and diagnostic logs to [email protected] or our WhatsApp desk (+880 1728-714614).

Technical Specifications

STC Lab Standards

Nominal Energy5.12 kWh

Nominal Voltage51.2 V

Rated Capacity100 Ah

Cell TypePrismatic LiFePO4 Cells

Max Continuous Discharge100 A

Cycle Life>6,000 cycles @ 80% DOD

Display InterfaceIntegrated Front LCD + LED SOC Bar

CommunicationCAN, RS485

Mounting StyleHeavy-duty wall mounting bracket

Dimensions & Weight650 x 480 x 165 mm, 48.0 kg

Protection RatingIP54 indoor rated enclosure

Recommended Use Cases

Applications & Project Fit

Industrial Fit

Garments & Textiles

Optimized for factory shed rooftop arrays under net-metering schemes.

Commercial Buildings

Reliable daytime yield and peak grid tariff reduction for corporate hubs.

Agro & Solar Irrigation

Clean off-grid power displacing expensive diesel generator pumping.

Grid-Tied & Hybrid BESS

Seamless synchronization with commercial inverters and storage banks.

Product FAQ

Questions About 48V 100Ah Wall-Mount LiFePO4 Battery

What are the primary applications for 48V 100Ah Wall-Mount LiFePO4 Battery?+

Ideal for commercial & industrial factory rooftops, textile RMG facilities, agricultural solar irrigation, and commercial grid-tied/hybrid systems.

Are factory flash test reports and datasheets included?+

Document availability depends on the model, shipment and current supplier file. Confirm which datasheet, test report or compliance document can be provided before ordering.

How does the warranty claim and local RMA support work?+

Warranty and RMA terms vary by model and manufacturer. Confirm the current warranty document, claim process and local coordination scope in writing before purchase.

What is the MOQ and delivery timeline in Bangladesh?+

Warehouse in-stock inventory is dispatched within 24–48 hours nationwide. Container-scale orders are delivered directly from port to your project site.
