12.8V 200Ah LiFePO4 Battery

2.56 kWh deep cycle drop-in replacement battery for 12V/24V/48V off-grid power systems.

Internal Noor SKU:NS-BAT-12200D

Stock Availability:Dhaka Warehouse In-Stock

Minimum Order Quantity (MOQ):2 units

Container Inquiries:Container pricing available on request

Request Wholesale Quotation

Direct B2B wholesale supply • Wholesale orders from 1 palletContainer pricing available on request

Engineering Summary

A direct replacement for conventional heavy lead-acid and AGM batteries in solar lighting, telecom repeater stations, and mobile power stations. Can be connected in series up to 48V or in parallel up to 800Ah for scalable decentralized power configurations.

Supplied with Complete Technical Datasheet

Warranty & Support

Factory Terms

Performance Warranty:>4,000 cycles @ 80% DOD

Manufacturer Warranty Backing

Standard warranty terms are provided and backed directly by the original equipment manufacturer.

Local Supplier RMA Coordination

Noor Solar Energy serves as the local technical liaison in Bangladesh, coordinating on-site diagnostics, factory RMA claims, and authorized component replacement with the manufacturer.

RMA Claim Submission:To initiate an RMA support claim, submit the original commercial invoice, serial numbers, and diagnostic logs to [email protected] or our WhatsApp desk (+880 1728-714614).

Technical Specifications

STC Lab Standards

Nominal Energy2.56 kWh

Nominal Voltage12.8 V

Rated Capacity200 Ah

ChemistryLiFePO4 Deep Cycle

Max Continuous Discharge100 A

Peak Discharge Current200 A (5s)

Cycle Life>4,000 cycles @ 80% DOD

Terminal PostM8 Stainless Steel Bolt

Case Material & RatingABS Flame Retardant (IP65)

Dimensions & Weight522 x 240 x 218 mm, 22.5 kg

Recommended Use Cases

Applications & Project Fit

Industrial Fit

Garments & Textiles

Optimized for factory shed rooftop arrays under net-metering schemes.

Commercial Buildings

Reliable daytime yield and peak grid tariff reduction for corporate hubs.

Agro & Solar Irrigation

Clean off-grid power displacing expensive diesel generator pumping.

Grid-Tied & Hybrid BESS

Seamless synchronization with commercial inverters and storage banks.

Product FAQ

Questions About 12.8V 200Ah LiFePO4 Battery

What are the primary applications for 12.8V 200Ah LiFePO4 Battery?+

Ideal for commercial & industrial factory rooftops, textile RMG facilities, agricultural solar irrigation, and commercial grid-tied/hybrid systems.

Are factory flash test reports and datasheets included?+

Document availability depends on the model, shipment and current supplier file. Confirm which datasheet, test report or compliance document can be provided before ordering.

How does the warranty claim and local RMA support work?+

Warranty and RMA terms vary by model and manufacturer. Confirm the current warranty document, claim process and local coordination scope in writing before purchase.

What is the MOQ and delivery timeline in Bangladesh?+

Warehouse in-stock inventory is dispatched within 24–48 hours nationwide. Container-scale orders are delivered directly from port to your project site.
